Google Workspace

lynox integrates with Google Workspace to read and write your business data. Once connected, you can ask lynox to check your email, create calendar events, analyze spreadsheets, and more.

Setup

You need a Google Cloud project with OAuth 2.0 credentials. This takes about 5 minutes.

Note

This setup is for your own Google Cloud project — self-hosted, Docker, or managed hosting where you prefer to bring your own OAuth client. Each project is separate, so no Google security audit of lynox is involved.

On lynox.cloud you can skip all of it

Managed instances can connect through lynox’s own Google client: one button on the Google card, no Cloud project, no client ID. The consent then asks for a deliberately narrow set — calendar events, free/busy, and the Drive files lynox itself creates. If you need more than that (reading Gmail, editing existing spreadsheets, full Drive), bring your own client with the setup below; the card offers it under Advanced.

1. Create a Google Cloud project

1. Open the Google Cloud Console
2. Click the project selector at the top → New Project
3. Name it (e.g. “lynox”) and click Create

If you already have a project, select it instead.

Caution

“You don’t have permission resourcemanager.projects.create” — your Google account is part of a Workspace organization but lacks the Project Creator role on it. Either:

• Pick “No organization” in the project-creation dropdown (works without extra rights), or
• Ask your Workspace Super Admin to grant you the Project Creator role at https://console.cloud.google.com/iam-admin/iam (select your org at the top, then Grant access → add your email → role Project Creator).

2. Enable APIs

1. In the sidebar, go to APIs & Services → Library
2. Search for each of these APIs and click Enable:

API name	What it’s used for
Gmail API	Read and send email
Google Drive API	Access files in Drive
Google Calendar API	Read and manage events
Google Sheets API	Read and edit spreadsheets
Google Docs API	Read and edit documents

Tip

You can copy each API name and paste it directly into the Library search bar.

3. Configure the OAuth consent screen

1. In the sidebar, go to OAuth consent screen
2. If you see “Google Auth Platform not configured yet”, click Get Started
3. App information — Enter an app name (e.g. “lynox”) and select your email as support email → Next
4. Audience — pick the right user type (see below) → Next
5. Contact information — Enter your email → Next
6. Finish → Click Create

Internal vs. External — pick the right one

User type	Pick when…	Tradeoffs
Internal (recommended if available)	You have a Google Workspace account and only Workspace users will connect	No Google verification ever, refresh tokens never expire, no test-user list
External	You use a personal @gmail.com account, or want non-Workspace users to connect	App starts in “Testing” mode: max 100 test users, and refresh tokens expire after 7 days. That expiry is tied to the publishing status, not to verification — see the note below

“Internal” only appears if your account belongs to a Workspace organization. If you don’t see it, pick “External”.

Caution

The 7-day refresh-token expiry is tied to the publishing status, not to verification. Google’s wording: a project “configured for an external user type and a publishing status of Testing is issued a refresh token expiring in 7 days” (OAuth 2.0 guide, read 2026-08-27). Switching the publishing status from Testing to In production therefore ends the 7-day expiry on its own — you do not have to complete verification first. The trade-off is that an app requesting sensitive or restricted scopes shows an unverified-app warning screen until verification is granted, and Google’s OAuth quota table caps such an app at “100 new users in total, after the app presents the unverified app screen”.

Verification and CASA are two different bars. Verification is free — Google says sensitive-scope verification “typically takes 3-5 business days” (read 2026-08-27) — and applies to sensitive scopes. The annual CASA security assessment applies only to restricted scopes — for Google Workspace that means full-mailbox and full-Drive access such as gmail.readonly, gmail.modify, drive and drive.readonly. Narrower scopes often cost less — calendar.events and documents.readonly are sensitive (verification, no CASA), and drive.file — files the app creates or the user explicitly picks — is not even sensitive.

But “narrower” does not help for Gmail, and that is the case most people look up. Every OAuth path to mailbox content is restricted, including the narrow-looking ones: gmail.readonly, gmail.modify, gmail.compose, gmail.metadata (headers only) and the IMAP scope https://mail.google.com/ are all on Google’s restricted list. The axis is how much data the scope exposes, not read-versus-write — which is why full calendar access including deletion is only sensitive, while a metadata-only mailbox scope is not. If you want mailbox access without a CASA assessment, an OAuth scope is not the route; lynox also supports plain IMAP/SMTP with an app password. Google publishes no per-scope list; the authoritative classification is shown in the Cloud Console under Google Auth Platform → Data access.

Note

External only — your app starts in “Testing” mode. Add yourself as a test user: OAuth consent screen → Test users → Add users → enter your Google email. Internal apps skip this step.

4. Create OAuth credentials

The application type depends on your deployment:

Self-hosted (Docker / local)

1. In the sidebar, go to Credentials
2. Click Create Credentials → OAuth client ID
3. Application type → select Desktop app
4. Name → enter anything (e.g. “lynox”)
5. Click Create
6. Copy the Client ID and Client Secret

Managed hosting (lynox.cloud)

1. In the sidebar, go to Credentials
2. Click Create Credentials → OAuth client ID
3. Application type → select Web application
4. Name → enter anything (e.g. “lynox”)
5. Authorized redirect URIs → click Add URI → enter https://<your-subdomain>.lynox.cloud/api/google/callback
6. Click Create
7. Copy the Client ID and Client Secret

Tip

The Web UI shows the exact redirect URI to copy — no need to type it manually.

Troubleshooting

Error	Cause	Fix
“Wrong client type”	Wrong application type for your deployment	Self-hosted: Desktop app · Managed: Web application
“Invalid Client ID”	Client ID is wrong or has extra whitespace	Copy the Client ID again from Credentials page
Device flow not starting	APIs not enabled	Verify all 5 APIs are enabled (step 2)
“Access blocked”	Not added as test user	Add your email under OAuth consent screen → Test users
Callback returns 401	Outdated lynox version	Update to the latest version
“redirect_uri_mismatch”	Redirect URI doesn’t match	Verify the URI in Google Console matches exactly

Configure

Via Web UI: Settings → Integrations → Google Workspace. Enter Client ID and Secret, then authorize.

Via environment variables:

export GOOGLE_CLIENT_ID=your-client-id.apps.googleusercontent.com
export GOOGLE_CLIENT_SECRET=GOCSPX-...

Authorization

lynox supports three OAuth flows:

Flow	Best for	Client type	How it works
Redirect	Managed hosting / web-hosted	Web application	Redirects to Google, sends you back after approval
Device Flow	Self-hosted Docker / headless	Desktop app	Shows a code to enter at google.com/device
Service Account	Server-to-server	—	Uses a key file, no user interaction

The Web UI detects your deployment and uses the correct flow automatically.

Access Level

The card offers two named levels. They are not “read” and “write” — Google’s own axis is how much data a scope exposes, which is why full calendar access including deletion is only sensitive while a headers-only mailbox scope is restricted.

Level	What it asks Google for	What that costs
Standard (default)	Your identity and email address, calendar events, free/busy, and the Drive files lynox creates (drive.file)	App verification. No CASA assessment — nothing in this set is restricted.
Full	Standard, plus Sheets, Docs, Calendar and Gmail-send, plus Gmail reading and full Drive	Verification and an annual CASA security assessment, because it includes restricted scopes.

What Standard does not include, so nothing here is a surprise later: no Gmail access of any kind, no access to spreadsheets or documents you did not create through lynox, and no access to Drive files lynox did not create. Asking lynox to read an existing spreadsheet on a Standard connection is refused with the scope it would need, not attempted and failed.

Choosing Full changes where your mail comes from. Full includes a Gmail read scope, and lynox then reads that mailbox over the Google connection instead of over IMAP. If you have the mailbox connected as IMAP as well, that is the switch to be aware of.

Switching levels requires re-authorising with Google. A connection made before these two levels existed keeps working and shows as legacy — nothing changes until you pick a level.

For advanced use, scopes can be set directly. The accepted list is wider than the two levels above, for two different reasons — and only the first is about you:

• Scopes lynox used to request. A connection made before the levels existed keeps working; nothing it was granted is rejected now.
• Scopes lynox has never requested but Google classifies, such as gmail.metadata or the blanket calendar. They are accepted if your grant already carries them; lynox will not ask for them.

Anything outside that list is rejected:

{
  "google_oauth_scopes": [
    "https://www.googleapis.com/auth/calendar.events",
    "https://www.googleapis.com/auth/drive.file"
  ]
}

What You Can Do

Gmail — only on a Full connection

Gmail is not part of the Standard set. On a Full connection your Gmail mailbox appears in Settings → Integrations → Mail alongside any IMAP/SMTP accounts, and the same mail tools (mail_triage, mail_search, mail_read, mail_send, mail_reply) work across all of them — there is no separate Gmail tool. On a Standard connection the mailbox is not registered at all and the card says so; connect it over IMAP with an app password instead.

• “What’s in my inbox today?” (spans Gmail + IMAP if you have both)
• “Find emails from [contact] about [topic]”
• “Draft a reply to the last email from [name]”
• “Send a follow-up to [contact]”

Google Sheets — only on a Full connection

Standard grants no Sheets access. A read on a Standard connection is refused naming the scope it needs.

• “Summarize the Q1 revenue sheet”
• “Add a row to my expenses tracker”
• “Compare last month’s numbers with this month”

Google Drive — files lynox created, unless you go Full

Standard grants drive.file, which reaches only what lynox itself created or you explicitly picked. Searches say so in their result rather than reporting an empty Drive.

• “Find the proposal document from last week” (only if lynox created it)
• “Summarize the PDF in my Drive called [name]” (same)

Google Calendar — in the Standard set

Creating, moving and deleting events needs no upgrade: calendar.events is part of Standard. Each change is confirmed before it happens.

• “What meetings do I have tomorrow?”
• “Schedule a call with [name] next Tuesday at 10am”
• “Block 2 hours for deep work this afternoon”

Google Docs — only on a Full connection

Standard grants no Docs access at all, reading included.

• “Summarize the meeting notes in [document]”
• “Update the project status section”

Token Storage

OAuth tokens are stored encrypted in the lynox vault (requires LYNOX_VAULT_KEY). Tokens refresh automatically — you only need to authorize once.

You can revoke access anytime via the Web UI (Settings → Integrations → Google → Revoke).
